Based on the Valeport miniSVS, the UV-SVP offers a formfactor designed for Underwater Vehicles where space is at a premium. Incorporating Valeport's class leading time of flight sound speed sensor, a PRT temperature sensor and a 0.01% pressure sensor in a compact package weighing just 750 grams (in air), the lightweight titanium housing gives a depth rating of 3000m. A wide range (9-30V DC) isolated power supply and RS232 communications complete the package.
Sensors
Sound Velocity
Each sound velocity measurement is made using a single pulse of sound travelling over a known distance, so is independent of the inherent calculation errors present in all CTDs. Our unique digital signal processing technique virtually eliminates signal noise, and gives an almost instantaneous response; the digital measurement is also entirely linear, giving predictable performance under all conditions.
Range: 1375 - 1900m/s
Resolution: 0.001m/s
Accuracy: ±0.020m/s
Temperature
Range: -5°C to +35°C
Resolution: 0.001°C
Accuracy: ±0.01°C
Pressure
Range: 10, 30, 100, 300
Resolution: 0.001% range
Accuracy: ±0.01% range
